The most powerful of our SHV™ series performs beautifully at both close and extended ranges on varmints, big game, and for making tight groups on paper.
You get outstanding clarity, crispness and color contrast at every magnification setting. It features a full 80 MOA of elevation adjustment, side parallax adjustment and ZeroSet™ technology which allows a quick return to your initial zero setting, regardless of how many elevation adjustments you’ve made.
It’s tough, reliable and big calibers won’t bother it. The SHV™ 5-20×56 won’t bother your finances too much, either.
| Magnification Range | 5-20x |
|---|---|
| Focal Plane | Second Focal Plane (F2/SFP) |
| Body Tube Diameter | 30mm |
| Overall Length | 15.2 in/386 mm |
| Mounting Length | 6.5 in/165 mm |
| Weight | 29.1 oz/825 g (non-illum) 30.5 oz/865 g (illum) |
| Click Value | .250 MOA or .1 MRAD |
| Internal Adjustment Range | E: 80 MOA W: 50 MOA |
| Parallax Adjustment | 25 yd–∞ |
| Eye Relief | 3.5 in/90 mm |
| Field of View @ 100 yd or m | 5x: 17.9 ft/6.0 m 20x: 5.0 ft/1.7 m |
| Exit Pupil | 5x: 8.7 mm 20x: 2.5 mm |
| Illumination | Analog (Optional) |
| Elevation Feature | ZeroSet |
| Power Throw Lever | Accessory |
